PULSE
Specialized valves dispatch
Pneumatically Actuated Globe Valve
IBR Certified Globe Valve
IPC Make Flameproof Limit Switch Box with Position Indicator
SIZE
(12") 300 MM
CERTIFICATION
IBR
PRESSURE RATING
#150
TESTING STD.
BS EN 12266-1
Technical Specifications
VALVE MAKE & SERIES
IPC - 813
CONSTRUCTION
OS & Y Type Bolted Bonnet
TYPE
Globe Valve
DESIGN STD
BS 1873
Face to Face
ASME B 16.10
End Connection
ASME B16.5, FE, RF
Paint
Heat Resistant Aluminim
Operating Temp
As per ASME B16.34
Operating Pressure
20 Kg/cm² Max
Leakage class
BS EN 12266-1, Rate - D
Flow Direction
Uni-Directional
Trim NO.
SS316L-(TR-52)
Body MOC
ASTM A 216 GR. WCB
Plug MOC
ASTM A351 Gr. CF3M
Stem MOC
ASTM A276 TP 316L
Seat MOC
ASTM A182 Gr. F316L
Actuator Type
Piston type Pneumatic Actuator
Function (Duty)
ON-OFF
Service
Steam
Air Fail Position
Close
